HP Latex R1000 Plus Printer

Print
Printing modes
161 ft²/hr (15 m²/hr) – Indoor High Quality (12p 120%)
301 ft²/hr (28 m²/hr) – Indoor Production (6p 110%)
603 ft²/hr (56 m²/hr) – Outdoor (3p 70%)
269 ft²/hr (25 m²/hr) – White Spot (100%)
118 ft²/hr (11 m²/hr) – White Overflood (100%)
39 ft²/hr (3.6 m²/hr) – 3 layers day & night

Print resolution – Up to 1200 x 1200 dpi
Ink types – Water-based HP Latex Inks
Ink cartridges – 9 (cyan, magenta, yellow, black, light cyan, light magenta, HP Latex Optimiser, HP Latex Overcoat, white)
Cartridge size – 3 L (colours, HP Latex Optimiser, HP Latex Overcoat); 3 L (white)
Printheads – 8 (cyan/black, magenta/yellow, light cyan/light magenta, HP Latex Overcoat, 2 HP Latex Optimiser, 2 white)
Long-term print-to-print repeatability – Average ≤ 1.0 dE2000, 95% of colours ≤ 2 dE2000

Media
Handling – Flatbed, sheet feed, roll feed, vacuum belt media drive for easy loading and accurate media advance
Media types – Rigid substrates: paper foamboard, plastic foamboard, PVC foam, plastic corrugated, acrylic, polycarbonate, polystyrene, compressed cardboard, corrugated board, honeycomb board, aluminum composite panel, wood, glass, ceramic; Roll substrates: PVC banner, self-adhesive vinyl, coated paper, polypropylene, polystyrene, polycarbonate, polyester, textile (non porous), canvas, leather
Rigid media size – 11.7 x 16.5 in to 64 x 48 in (297 x 420 mm to 1625 x 1220 mm) up to 64 x 120 in (1625 x 3050 mm) with two sets of optional extension tables
Roll size – 24 to 64 in (60.9 cm to 1.63 m)
Roll weight – Up to 150 lb (Up to 68 kg)
Roll diameter – Up to 9.8 in (Up to 25 cm)
Thickness – Up to 2 in (50.8 mm)

Applications
Signage: indoor, flat, backlit, thermoformed; Decoration: wall coverings, window decoration; Vehicle decoration: fleet graphics, wraps, decals; Textile: soft signage, frontlit, backlit; POS and Packaging: corrugated displays, short-run customized packaging, prototyping

Connectivity
Interfaces – Gigabit Ethernet (1000Base-T)

Dimensions (W x D x H)
Printer – 166 x 80 x 69 in (4.21 x 2.04 x 1.75 m) printer; 166 x 143 x 69 in ( 4.21 x 3.64 x 1.75 m) including standard input and output tables
Shipping – 174 x 88 x 85 in (4.43 x 2.24 x 2.15 m)
Operating area – 21.7 x 19.8 x 9.8 ft (6.61 x 6.03 x 3 m)

Weight
Printer – 1400 kg
Shipping – 2400 kg

Environmental ranges
Operating temperature – 15 to 30ºC
Operating humidity – 20 to 70% RH (non-condensing)

Power
Consumption 8 to 10 kW (typical)
